| Camera | |
|---|---|
| Image Sensor | 1/2.7” 8-Megapixel Progressive Scan CMOS Sensor |
| Minimum Illumination | 0.01 Lux @(F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | Self-adaptive shutter |
| Lens | 2.8mm@ F1.6; 135° (Diagonal), 113° (Horizontal), 60° (Vertical) |
| Day & Night | IR-Cut filter with auto-switching |
| DNR | 3D DNR |
| Night Vision | IR Distance: 15m, Color Night Vision Distance: 15m |
| Video & Audio | |
| Max. Resolution | 3840*2160/4K/8MP |
| Frame Rate | 15fps, self-adaptive during network transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Ultra HD; Quad HD; Full HD; Hi-Def Adaptive bit rate |
| Audio Bit Rate | Self-adaptive |
| Max. Bitrate | 4 Mbps |
| Network | |
| Bluetooth | Supports |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n, 802.11ax |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | WPA-PSK/WPA2-PSK, WPA3-Personal |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps, 11ax: 114Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Minimum Network Requirement | 8Mbps |
| Function | |
| Smart Alarm | AI-Powered Human Shape Detection, AI-Powered Vehicle Detection |
| Two-way Talk | Supports |
| General Function | Anti-Flicker, Heart Beat, Password Protection, Watermark |
| General | |
| Operating Conditions | -20 °C to 50 °C (-4 °F to 122 °F), humidity 95% or less (Non-condensing) |
| IP Grade | IP65 |
| Power Supply | DC 5V/2A (compatible power adapter to be purchased separately) |
| Battery Capacity | 10400 mAh |
| Power Consumption | Max. 10W |
| Product Dimensions | 149.33 x 62.95 x 62.95 mm |
| Packaging Dimensions | 103 x 103 x 186 mm |
| Weight | Net Weight: 348g; With Package: 671g |
| Performance Parameter* | |
| Power Voltage | 6.36V ±5% |
| Max. Power Current | 660mA ±5% |
| Max. Power | 4.2W |
| Solar Cell Efficiency | 21.6% |
| Operation Temperature | -2060°C (-4140°F), Humidity 90% or less (non-condensing) |
| Note | *The working environment temperature for battery camera charging should be maintained at 0-45°C |
| IP Grade | IP65 |
| Mechanical Data | |
| Solar Cell Type | Monocrystalline solar cells |
| Product Dimensions | 216.25 × 149.58 × 2.4 mm (8.51 × 5.89 × 0.09 inch) |
| Packaging Dimensions | 230 × 161 × 78 mm (9.06 × 6.34 × 3.07 inch) |
| Weight | With package: 611 g (21.5 oz), Panel body without bracket: 334 g (11.78 oz) |
| In the box | |
| Contents | EZVIZ Solar Panel-F; EZVIZ BC1c Camera; Magnetic Base; Adjustable Mounting Bracket; Screw Base; USB Cable; Screw Kit ×2; Drill Template ×2; Regulatory Information; Quick Start Guide; Pin |
| Certifications | CE / WEEE / ROHS / REACH |
